Hot Sale 28khz 1200w Plastic Welders Transducer Booster Flange Ultrasonic Horn For Welding

1 Piece
MOQ
$46.00(1 - 4 Pieces) $45.00(>=5 Pieces)
Precio
Hot Sale 28khz 1200w Plastic Welders Transducer Booster Flange Ultrasonic Horn For Welding
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Condition: New
Voltage: 220v
Frequency: 28KHz
Welding Area: 8x10mm
Dimensions: 18x5x5cm
Usage: welding transducer
Warranty: 6 Months
After-sales Service Provided: Online support, Video technical support
Key Selling Points: Long Service Life
Applicable Industries: Manufacturing Plant, Food & Beverage Factory
Weight (KG): 0.64 KG
Power (kW): 1200w
Marketing Type: Ordinary Product
Machinery Test Report: Provided
Video outgoing-inspection: Provided
Color: Silver
Product name: 20khz 2000w Welding Transducers Replacement Ultrason
Application: Plastic Welders
Function: Welding
Welding Speed: 0.1s
For Suitable Materials: NON-WOVEN/PVC/PE/PP/ABS
Daily protection: The normal temperature air cooling
MOQ: 1PCS
Other name: Ultrasonic oscillator
Packing: Foam boxes, cartons, wooden cases
After Warranty Service: Video technical support, Online support
Local Service Location: China
Showroom Location: China
Información básica
Pago y Envío Términos
Packaging Details: 1pc1package,20pcs per cotton
Descripción de producto
Product Description
Features:
The transducer converts high-frequency electrical energy into high-frequency mechanical vibrations. And it contains several piezoelectric ceramic discs sandwiched under pressure between two metal blocks. Between each disc is a thin metal plate, which forms the electrode. When a sinusoidal electrical signal is fed to the transducer via the electrodes, the discs expand and contract, producing axial vibrationsUltrasonic system is divided into three parts, ultrasonic generator, ultrasonic transducer and ultrasonic die, with the three parts is a complete ultrasound system.
Applications:
Paper Cup Making Machine, Nonwoven Machinery, such as Nonwoven Bag Making Machine, Nonwoven Surgical Cap Making Machine, Nonwoven Bouffant Cap Making Machine, Nonwoven Shoe Cover Making Machine, Nonwoven Ultrasonic Plastic Welding Machine, Ultrasonic Lace machine, Three Layers Bag Making Machines, Plastic Bag Making Machine, Stationery, Machinery,Automation Equipment, etc.
Specification
power
1200W
Capacitance
7Nf
Piezoelectric ceramic
Pzt8-38x15x6mm
Color of Piezo
Yellow
Quantity of Piezo
4pcs
Frequency Range
28KHz
Application
Welding
Ambient temperature
5~50degrees
Weight
0.64kg
Wave form
Long Wave/Intermittent Wave
Origin
China Zhejiang
Joint boilt
3/8-24/M12*1.75
Certificate
CE
